PAUT And TOFD Plate TO Plate Weld Flawed Specimen Double V 2” (Inch Version) Carbon Steel

PAUT And TOFD Plate TO Plate Weld Flawed Specimen Double V ASYMMETRICAL 1/3+2/3 THK

Time-of-flight diffraction ultrasonic (TOFD)-PLATE Weld Joint Flawed Specimen-Phased Array Ultrasonic Testing (PAUT)

Geometry: Plate to Plate Double V Butt Weld 20” Long and 10” Wide on Either Side of The Weld thickness range > 1.2” to 2” (Carbon Steel) ASYMMETRICAL 1/3+2/3 thickness.

Material: Carbon Steel

Flaws: 3 per specimen, randomly placed Specimen Tolerance: +/- 0.080"

Documentation: NDT Verification Reports, C of C, CAD Drawings and Test Sheets.

Customized Calibration Test Block and Flaw Specimen also available.
